Рассмотрен основной комплекс задач, решаемых инженером-электриком при разработке и модернизации электрооборудования промышленного оборудования, выполненного на базе программируемых логических контроллеров (PLC). В качестве основной базы рассматриваются металлорежущие станки, как универсальные, так и с числовым программным управлением. Материал книги излагается в последовательности реального проектирования электрооборудования и алгоритмов PLC, выполняемого в конструкторских бюро: изучение объекта автоматизации, выбор устройств управления, подключение и общая блок-схема, синтаксис языка программирования, параметры, типовые решения, примеры реальных проектов. Дана инженерная методика проектиров
